Black & Decker Wiring Diagrams - Editors of CPi
The editors of Creative Publishing, international, now bring you the ebook Quick Read: Wiring Diagrams. This quick read, excerpted from the best-selling The Black & Decker Complete Guide to Wiring, 5th edition, includes circuit maps for common household circuits. The arrangement of switches and appliances along an electrical circuit differs for every project. This means that the configuration of wires inside an electrical box can vary greatly, even when fixtures are identical. The circuit maps included here show the most common wiring variations for typical electrical devices. Most new wiring you install will match one or more of the maps shown. Find the maps that match your situation and use them to plan your circuit layouts. If you would like additional, related wiring information, look for The Black & Decker Complete Guide to Wiring, 5th edition.
